| Order Identification | |||||
| Example of Linear Encoder: GOX - 1640 - 5 - A | |||||
| G | O | X | 1640 | 5 | A |
| Type of profile for wide space |
Type of reference mark: • Blank space: Incremental, one mark every 50 mm • 0: Distance-coded marks • S: Selectable reference marks |
Type of signal: • X: 1 µm resolution differential TTL • Y: 0.5 µm resolution differential TTL • W: 0.1 µm resolution differential TTL • Z: 0.05 µm resolution differential TTL • P: 1 Vpp sinusoidal |
Measuring lengths in millimeters: In the example (1640) = 1 640 mm |
Accuracy of the linear encoder: • 5: ± 5 µm • 3: ± 3 µm |
Air intake on the reader head: • Blank space: Without air intake • A: With air intake |
