1 / 2
| Principal application | Tool measuring and broken tool detection on all sizes of vertical and horizontal machining centres. | |
| Transmission type | Hard-wired transmission | |
| Compatible interfaces | MI 8-4, HSI or HSI-C | |
| Recommended styli | Square tip stylus (tungsten carbide, 75 Rockwell C) | |
| Weight with disc stylus | 660 g (23.28 oz) | |
| Cable (to interface) | Specification | Ø5.2 mm (0.2 in), 2-core screened cable, each core 72 × 0.08 mm |
| Length | 5 m (16.4 ft) | |
| Electrical connection | Cable on the side of unit | |
| Sense directions | ±X, ±Y, +Z | |
| Unidirectional repeatability | 1.00 μm (40 μin) 2σ (note 1) | |
| Stylus trigger force (notes 2 and 3) |
XY low force: 0.65 N, 66 gf (2.34 ozf)
XY high force: 1.42 N, 145 gf (5.11 ozf)
Z direction: 5.50 N, 561 gf (19.78 ozf)
|
|
| Sealing | IPX8 (EN/IEC 60529) | |
| Mounting | M4 bolts (x 3) | |
| Operating temperature | +5 °C to +55 °C (+41 °F to +131 °F) | |
