The unit controls one servo motor with a rated output of 1.0 kW.
It uses advanced motion control technology including sine wave PWM regulation and fully closed-loop control to ensure high accuracy and smooth operation.
The drive unit features a built-in dynamic brake, allowing for rapid and reliable stopping capabilities.
A standard built-in regenerative resistor (100 W capacity) efficiently converts excess energy into reusable power, reducing overall system costs.
This feature incorporates a "Delay (D) Control" to the speed control loop, which helps mitigate overshoot and ensures stability, even with linear scales that provide immediate machine-end positional feedback.
Includes a function that allows users to precisely control the motor's torque limits, useful for stopper functions and exact reference positioning.
With an IP20 protection rating and forced-air cooling, the unit is built for demanding industrial environments and features a space-saving design.
| Feature | Specification |
|---|---|
| Rated Output Power | 1.0 kW |
| Rated Input Current | 5 A (3-phase) |
| Rated Output Current | 11 A |
| Input Voltage | 3-phase 200–230 VAC, 50/60 Hz |
| Compatible Motors | Designed for use with Mitsubishi HF series servo motors |
| Protection Rating | IP20 |
| Cooling Method | Forced air cooling (built-in fan) |
DingYan Machinery offer all the parts of Fanuc brand items. Products contains all the accessories of CNC controller, drivers and amplifier, encoder, motor, IO modules, fan and other spare parts.
We want to be your final one-stop CNC machine tool accessories supplier, we have most Fanuc products in stock, let’s help you be more successful in your market!
Dingyan is not an authorized distributor, reseller, or representative of any products displayed on this website. All trademarks, logos, and brand names are the exclusive property of their respective owners. Product references are for identification purposes only and do not imply endorsement, affiliation, or authorization.
If you require any product assistance or support, we are happy to provide it.
DingYan Machinery is committed to creating safe, reliable, and high-performance products for our customers. Furthermore, we will continue to strive to provide more products and brands upon customers’ requirement. Should you have any inquiry, please kindly send us emails or call us.
The servo drive unit delivers a rated output power of 1.0 kW and operates on a 3-phase input voltage of 200–230 VAC at 50/60 Hz.
This unit is engineered specifically for compatibility with Mitsubishi HF series servo motors.
Yes. It features a built-in dynamic brake for quick stopping, alongside a 100 W regenerative resistor that efficiently recycles excess energy to reduce operational power costs.
